Product Information

Electric Pure Steam generator price for pharmaceutical is mainly used for the disinfection and sterilization in the pipes, containers and other

equipments of pharmaceuticals, medical treatment sanitation, biological and food industry. It is an important part of big

transfusion production line. It can effectively avoid the substance repollution caused by the impurities such as heavy

metal progon and so on. Besides, it meets the GMP and CGMP demands

 Technical characteristics

1. Material: the contact parts with feed water,pure steam and WFI all adopt SS316L

2. Electro-polish: to assure the quality of WFI and increase the life of equipment, stainless steel surface is treated by polishing.

3. double tube plate design: the design of external preheater, condenser and the effect evaporator are double tube plates, complying with requirements of CGMP,preventing the possibility of low sanitation level media polluting system.

4. All heat surfaces have jackets and is crossed by 304 stainless steel outside.

5. The equipment has no moving parts and is operated quietly and safely.

6. Controlled by PLC, standard procedure

7. Integrated documents validation and service system.

8. Easy operation and maintenance

9. Control system: using PLC control technology to meet different customers’ requirements. From the analysis and distribution of pure steam quality to higher control, such as each media continuous regulation, storage system linkage, classification password control and evaporation quantity etc, we all can check carefully.

10. Whole equipment performance test: according to certain procedure, simulating the real environment to do the test in testing workshop.
